Author Topic: "Cubierto" 0n30  (Read 13312 times)
lucas gargoloff
Full Member
***
Offline Offline

Posts: 107


« on: March 20, 2010, 06:04:26 PM »

Since a long time!! I have no much time for the hobbie, but last week had a little extra time... so let´s show what I did...
This is a box car (called cubierto here), from La Trochita, the glorious Old Patagonian Express. I made it from styrene with many fittings from Grandt Line, couplers are from San Juan. Here´s a pic of the prototype, the model in procces and how it looks today, still needs lettering and light weathering.
Hope you like it!










Logged

Lucas Gargoloff - Argentina
lab-dad
Hero Member
*****
Offline Offline

Posts: 2091



« Reply #1 on: March 20, 2010, 07:12:21 PM »

Welcome back!
Nice to see you modeling again!
Very nice model, I look forward to seeing it finished!
-Marty
Logged

     Martin G. Jones Photography
    Go not where the path leads
Go instead, where there is no path,
           And leave a trail
Ray Dunakin
Hero Member
*****
Offline Offline

Posts: 3783



WWW
« Reply #2 on: March 20, 2010, 07:39:57 PM »

Nice work!
Logged

Visit my website to see pics of the rugged and rocky In-ko-pah Railroad!

Ray Dunakin’s World
SDwn
Newbie
*
Offline Offline

Posts: 48


« Reply #3 on: March 21, 2010, 06:50:27 PM »

      Nice looking model Lucas. I was curious on how you painted the trucks. Do you mask off the unpainted areas or scrape the paint off from the wheel/ flange? I am always looking for an easier way to paint them. Thanks  Sean
Logged
lucas gargoloff
Full Member
***
Offline Offline

Posts: 107


« Reply #4 on: March 21, 2010, 08:58:33 PM »

Thanks for the replies guys!
Sean: I painted the trucks and wheels separately, then when paint was dried, I mount again wheels on trucks and roll them over a rag dipped in thinner, easy way to remove paint from flanges.
Logged

Lucas Gargoloff - Argentina
SDwn
Newbie
*
Offline Offline

Posts: 48


« Reply #5 on: March 23, 2010, 12:37:06 AM »

    Thanks Lucas, I will have to give that a try.  Sean
Logged
lab-dad
Hero Member
*****
Offline Offline

Posts: 2091



« Reply #6 on: March 23, 2010, 06:13:41 AM »

Sean,
I made a jig with 4 holes in it the size of the wheels and the thickness about 1" by 3" - 2 pc.
Place the wheels in the jig and rubber band the two plates.
Paint away!
-Marty
Logged

     Martin G. Jones Photography
    Go not where the path leads
Go instead, where there is no path,
           And leave a trail
marc_reusser
Curmudgeon
Administrator
Hero Member
*****
Offline Offline

Posts: 4519



WWW
« Reply #7 on: March 25, 2010, 01:38:48 PM »

Neat project and subject Lucas. Thanks for posting. Look forward to your progress.

Marc
Logged

I am an unreliable witness to my own existence.

In the corners of my mind there is a circus....

M-Works
lucas gargoloff
Full Member
***
Offline Offline

Posts: 107


« Reply #8 on: April 02, 2010, 04:06:25 PM »

Thanks Marc!
Lettering is completed as seen on the prototype. Started in weathering too.



Logged

Lucas Gargoloff - Argentina
lucas gargoloff
Full Member
***
Offline Offline

Posts: 107


« Reply #9 on: June 03, 2010, 05:09:41 PM »

Now, I can say the "Cubierto" is finished in 99%, maybe some adds after your comments, why not? Weathering is done with Bragdon Powders mixed with MicroSet.







And some closeups from the underbody...





Thanks for watching!

Logged

Lucas Gargoloff - Argentina
Tom Neeson
Full Member
***
Offline Offline

Posts: 113



« Reply #10 on: June 03, 2010, 05:23:44 PM »

Nice model there Lucas. What couplers are you using?

Tom
Logged

No Scribed Siding!
lucas gargoloff
Full Member
***
Offline Offline

Posts: 107


« Reply #11 on: June 03, 2010, 05:26:11 PM »

Thanks Tom, couplers are San Juan 0n3 Evolution.
Logged

Lucas Gargoloff - Argentina
marc_reusser
Curmudgeon
Administrator
Hero Member
*****
Offline Offline

Posts: 4519



WWW
« Reply #12 on: June 03, 2010, 05:47:22 PM »

Looks good, but you are missing the wood stringers/beams that were used to hold down the currugated metal roofing at the outer ends. This was common/typical practice on corrugated roofs, and you look closely, you can see them in the prototype photo.

Sorry, the only image/example I could quickly find. Note the stringers/beams on the roof towards the car sides.




Logged

I am an unreliable witness to my own existence.

In the corners of my mind there is a circus....

M-Works
lucas gargoloff
Full Member
***
Offline Offline

Posts: 107


« Reply #13 on: June 03, 2010, 05:51:33 PM »

Yes Sir!!! you´re right!! How could I forgot this?? So, thanks for note that, will work on this next weekend.
Thanks again!
Logged

Lucas Gargoloff - Argentina
lab-dad
Hero Member
*****
Offline Offline

Posts: 2091



« Reply #14 on: June 04, 2010, 06:56:24 AM »

Looking really god, nice to see you back!
You swing in and out like a pendulum!
The only comment I can make is the "rust" seems too monochromatic to me.
Some darker/other colors should be present.
And may be some wear on the grab irons (done with a graphite pencil)
-Marty
Logged

     Martin G. Jones Photography
    Go not where the path leads
Go instead, where there is no path,
           And leave a trail
