Author Topic: The SketchUp Plymouth DL  (Read 48599 times)
lab-dad
Hero Member
*****
Offline Offline

Posts: 2083



« Reply #45 on: June 08, 2015, 06:49:13 AM »

Thanks Marc!
Thats why Unc wanted to do this project "on line" so we could all learn.
I need to look into the "fillet" tool as i would like a fillet on all the edges.

No big deal to redo the parts, I can do a sideframe in about an hour now!

-Marty
Logged

     Martin G. Jones Photography
    Go not where the path leads
Go instead, where there is no path,
           And leave a trail
TRAINS1941
Hero Member
*****
Offline Offline

Posts: 1359


« Reply #46 on: June 08, 2015, 07:28:47 AM »

Looks great so far Marty.

Jerry
Logged

Why isn't there mouse-flavored cat food?
George Carlin
Franck Tavernier
Sr. Member
****
Offline Offline

Posts: 307


WWW
« Reply #47 on: June 08, 2015, 11:00:04 AM »

Hi Marty, Russ,

Is it a 7 or 8 ton model? I'm working on a freelance gas loco in 1:35 scale, inspired by the RLD 3.3 ton :



Do you think that it would be possible to print it in 1:35?

Franck
Logged

finescalerr
Administrator
Hero Member
*****
Offline Offline

Posts: 5724


« Reply #48 on: June 08, 2015, 12:42:58 PM »

Ours is an 8 ton model, Franck. By the way, I think Chuck has drawn a Plymouth similar in appearance to the loco you posted.

As for printing, as I drew the loco I realized it has many parts too small or thin to print in 1:32 (or 1:35). That is why we have started this thread -- to learn what we can print, what we must scratchbuild, and what we must modify.

Russ
Logged
Chuck Doan
Mr. Wizard
Hero Member
*****
Offline Offline

Posts: 2522



WWW
« Reply #49 on: June 08, 2015, 03:42:53 PM »

Mine was a different freelanced design, but Bill Gould has some gorgeous plans for this (or a similar) loco to the one in Francks plan:

http://www.gouldstudios.com/loco_PlymouthGas.html

If I could render like Bill or Wayne Rayner, I would probably give up real models altogether.

« Last Edit: June 08, 2015, 03:48:22 PM by Chuck Doan » Logged

“They're most important to me. Most important. All the little details.” -Joseph Cotten, Shadow of a Doubt





http://public.fotki.com/ChuckDoan/model_projects/
Franck Tavernier
Sr. Member
****
Offline Offline

Posts: 307


WWW
« Reply #50 on: June 09, 2015, 03:55:32 AM »

Chuck, if I'm not mistaken, you can buy the 3D drawing from Gould Studio...

http://www.turbosquid.com/3d-models/gas-mechanical-contractor-s-locomotive-3d-obj/542868

Franck
« Last Edit: June 09, 2015, 04:00:57 AM by Franck Tavernier » Logged

finescalerr
Administrator
Hero Member
*****
Offline Offline

Posts: 5724


« Reply #51 on: June 09, 2015, 12:32:34 PM »

If I could render like that I'd probably stop building, too. Bill's weathered rendering isn't quite up to the unweathered version but the work is still impressive. -- Russ
Logged
lab-dad
Hero Member
*****
Offline Offline

Posts: 2083



« Reply #52 on: June 09, 2015, 12:36:44 PM »

You cant play with renderings.
It's much more satisfying to see an idea move and function.

Marty - still not sold on this 3d stuff....
Logged

     Martin G. Jones Photography
    Go not where the path leads
Go instead, where there is no path,
           And leave a trail
Frederic Testard
Hero Member
*****
Offline Offline

Posts: 634



« Reply #53 on: June 09, 2015, 12:56:11 PM »

I agree, Marty. That becomes a totally different game.
Logged

Frederic Testard
finescalerr
Administrator
Hero Member
*****
Offline Offline

Posts: 5724


« Reply #54 on: June 10, 2015, 01:18:30 AM »

Well, better, worse, or equal, I still intend to create an actual model from my drawing. Two, actually, because SketchUp has frustrated Marty and he has assigned me the job of creating the kits. I hope to talk to Marty over the weekend about how to break the thing into practical subassemblies and then, when my drawings get all messed up, ask you guys for help! -- Russ
Logged
marc_reusser
Curmudgeon
Administrator
Hero Member
*****
Offline Offline

Posts: 4504



WWW
« Reply #55 on: June 15, 2015, 02:22:59 AM »

Side-frames for 1/32 (wall thickness are prototype 1"...which scales out to somewhere between .025 and .030")


* Sideframes_GreyLegoPlastic.jpg (131.49 KB, 800x437 - viewed 722 times.)
« Last Edit: June 15, 2015, 04:10:06 AM by marc_reusser » Logged

I am an unreliable witness to my own existence.

In the corners of my mind there is a circus....

M-Works
marc_reusser
Curmudgeon
Administrator
Hero Member
*****
Offline Offline

Posts: 4504



WWW
« Reply #56 on: June 15, 2015, 03:01:44 AM »

A basic render of Russ' SU file before the interior side-frame changes. The render really shows what a great job Russ did in the drafting/modeling of the loco.

Logged

I am an unreliable witness to my own existence.

In the corners of my mind there is a circus....

M-Works
marc_reusser
Curmudgeon
Administrator
Hero Member
*****
Offline Offline

Posts: 4504



WWW
« Reply #57 on: June 15, 2015, 03:58:19 AM »

Multi-part frame approach.

I would probably go so far as to omit the frame assembly bolts from the printing file, and then just add them with the proper NBW castings after.


* Frame_Parts_Assembly_Render.jpg (168.64 KB, 800x508 - viewed 710 times.)
« Last Edit: June 15, 2015, 04:19:14 AM by marc_reusser » Logged

I am an unreliable witness to my own existence.

In the corners of my mind there is a circus....

M-Works
lab-dad
Hero Member
*****
Offline Offline

Posts: 2083



« Reply #58 on: June 15, 2015, 05:58:42 AM »

Those look amazingGrin Grin Grin Grin Grin
Did you use Russ' original files to start with or start over?
What plug in did you use for the rendering?
Please tell us more!
Are they ready for printing?
Could they be scaled up to 1/16th?

Only suggestion would be to make the inside support for the axle/bearings as thick as the horse shoe shaped projection - just for strength but that is just being picky and over engineering!

-Marty
« Last Edit: June 15, 2015, 06:02:24 AM by lab-dad » Logged

     Martin G. Jones Photography
    Go not where the path leads
Go instead, where there is no path,
           And leave a trail
Mr Potato Head
Hero Member
*****
Offline Offline

Posts: 545



« Reply #59 on: June 15, 2015, 08:22:02 AM »

Russ
when your complete I'd love a copy and or please order me one from shapeways  Grin Grin Grin
MPH
Logged

Gil Flores
In exile in Boise Idaho
