Author Topic: Freight House  (Read 7774 times)
lucas gargoloff
Full Member
***
Offline Offline

Posts: 104


« on: December 10, 2008, 04:39:46 PM »

Well, this is my first steps in structures in 0 scale.
Ive just start with my first scratch structure in this scale. Ive been model H0 for many years, and change to 0n30 few month ago. I start this building with many laser cuts, first I draw in CAD and cut in laser in a 1mm sheet. Side walls are 2mm MDF, I decided to cut in laser because I havent to do all cuts for windows and doors. Then I glue hand scribbed sidding wood. How am planning to add interior, I Have to do interior walls in MDF too, but not laser cut.
Send pics of the shhets with many parts I cut.
I know i was wrong in the measures of the sidding wood, I will change it in the other sides.
Hope you enjoy!
Lucas





Logged

Lucas Gargoloff - Argentina
marklayton
Full Member
***
Offline Offline

Posts: 170



« Reply #1 on: December 10, 2008, 09:03:00 PM »

Lucas -

Very impressive.  What laser machine do you use to cut the wood?

Mark
Logged

He who dies with the most tools wins.
lucas gargoloff
Full Member
***
Offline Offline

Posts: 104


« Reply #2 on: December 10, 2008, 09:11:39 PM »

Thanks Mark. A friend of mine has the laser cut machine. Is a Versa VLS series.
I can find it, I think the VLS2.30 is the same he has:
http://www.hobartlasers.co.uk/content.php?sid=48&psid=33
Cheers!

Logged

Lucas Gargoloff - Argentina
marklayton
Full Member
***
Offline Offline

Posts: 170



« Reply #3 on: December 10, 2008, 09:18:59 PM »

Thanks, Lucas.

Just looked on the web and found a US supplier with a price list.  Not inexpensive, but not as bad as I was expecting.
http://www.engraversnetwork.com/specs/VersaLaser_pricing.pdf

Mark
Logged

He who dies with the most tools wins.
lucas gargoloff
Full Member
***
Offline Offline

Posts: 104


« Reply #4 on: December 10, 2008, 09:24:06 PM »

They arent cheapper than we expects. If I could have it, I only do cuts for my hobbie, but my wife will kill me!!! Cheesy Cheesy Cheesy
My friend use it for work all day cutting "my things", and doing all you can imagine.
Logged

Lucas Gargoloff - Argentina
lucas gargoloff
Full Member
***
Offline Offline

Posts: 104


« Reply #5 on: December 18, 2008, 04:06:11 AM »

I will add an open shed at one side. Ive scratch it with wood and add some NBW from Grandt Line.





Logged

Lucas Gargoloff - Argentina
lucas gargoloff
Full Member
***
Offline Offline

Posts: 104


« Reply #6 on: December 18, 2008, 04:10:34 AM »

Yesterday was playing with plaster castings. I have to do the basement, I said playing, because I never tried it before. Im satisfied with results, now I have to paint it. You can see all tools used.










Logged

Lucas Gargoloff - Argentina
lab-dad
Hero Member
*****
Offline Offline

Posts: 2083



« Reply #7 on: December 18, 2008, 07:59:34 AM »

Looking good Lucas.
You have had better luck on the stones than I did!
I would suggest looking at "New England Brownstone" he has a website, it is the best stone work I have ever seen.
He also has a TON of proto pics.
The open air shed is cool too.
Logged

     Martin G. Jones Photography
    Go not where the path leads
Go instead, where there is no path,
           And leave a trail
lucas gargoloff
Full Member
***
Offline Offline

Posts: 104


« Reply #8 on: December 18, 2008, 08:52:00 AM »

Thanks Marty!! This page help me a lot!! Now I will make a couple of stone walls and try molds with silicone for make more!!!
Regards
Logged

Lucas Gargoloff - Argentina
jacq01
Hero Member
*****
Offline Offline

Posts: 1110



« Reply #9 on: December 18, 2008, 09:00:34 AM »


  Lucas,

  a pity you brushed the wall after you carved out the stones. Now the brush lines are accentuated as they run all in the same direction. The stones directly from the wrinkled al. foil look much better.

 Jacq
Logged

put brain in gear before putting mouth in action.
never underestimate the stupidity of idiots
I am what I remember.
lucas gargoloff
Full Member
***
Offline Offline

Posts: 104


« Reply #10 on: December 18, 2008, 09:24:28 AM »

Thanks Jaq, maybe youre right. I noticed it when compare the pics. Will try more, off course.
Cheers
Logged

Lucas Gargoloff - Argentina
